Compact brushless motor kit featuring a precision 11-tooth brass pinion, optimized for Traxxas TRX-4M crawler by Komodo and Furitek

Description

This is the Furitek TRX-4M Micro Brushless Motor by Komodo. This smaller size and lightweight Micro 1212 3450kV brushless motor offers incredibly high torque with incredible low speed control helping you get the ultimate performance out of your TRX-4M.

Note: Lizard v2, Lizard PRO and Lizard Ultimate Electronic Speed Controllers are highly recommended to pair with this micro Komodo motor.

Features:

• Perfect fit for the the stock TRX-4M transmission
• 11T Brass pinion gear
• 12 Pole hi-torque motor design
• High quality Japanese NMB ball bearing
• Precision balanced rotor with supreme smoothness for extreme reliability and maximum RPM
• CNC machined 6061 T6 billet aluminum heatsink can
• High purity and higher temperature single copper windings
• Excellent heat dissipating to maximize efficiency

Specifications:

• Type: Brushless Outrunner
• kV rating: 3450kV
• Input voltage: 2-3S LiPo
• Motor size: 15.5×20.6mm
• Shaft size: 2x6mm
• Weight: 17.5g
• Max current: 10A
• No-load current @10V: 0.7A

Includes:

• (1) Furitek TRX-4M Micro Brushless Motor w/ 11T brass pinion for Komodo
