Description
| XO-1 (#64077-3) SPECS |
| Length: |
|
27 inches (686 mm) |
| Front Track: |
|
11.61 inches (295 mm) |
| Rear Track: |
|
11.81 inches (300 mm) |
| Center Ground Clearance: |
|
0.59 inches (15 mm) |
| Weight: |
|
137.6 ounces (3.9 kg) (w/o batteries) |
| Height (overall): |
|
5 inches (127.5 mm) |
| Wheelbase: |
|
15.9 inches (404 mm) |
| Front Shock Length: |
|
83 mm |
| Rear Shock Length: |
|
86 mm |
| Front Tires (pre-glued): |
|
Belted slick (4.29″ x 1.7″) |
| Rear Tires (pre-glued): |
|
Belted slick (4.29″ x 2″) |
| Front Wheels: |
|
3.3″ Split-Spoke™ (black-chrome)
with 17 mm splined hex |
| Rear Wheels: |
|
3.3″ Split-Spoke™ (black-chrome)
with 17 mm splined hex |
| Speed Control Type: |
|
Castle Mamba Monster Extreme
forward/reverse/brake |
| Motor (electric): |
|
Traxxas Big Block Brushless (1650 kV) |
| Transmission: |
|
Single-speed |
| Overall Drive Ratio: |
|
9.36 (stock, out-of-box) |
| Differential Type: |
|
Sealed hardened steel bevel |
| Gear Pitch: |
|
Module 1.0 |
| Chassis Structure/Material: |
|
3mm plate, dual plane, 6061-T6 aluminum |
| Brake Type: |
|
Electronic |
| Drive System: |
|
Shaft-driven 4WD |
| Steering: |
|
Bellcrank |
| Transmitter: |
|
TQi™ 2.4GHz Radio System with Traxxas Link Wireless Module |
| Receiver: |
|
TSM® Receiver (#6533) |
| Top Speed: |
|
100+mph |
| Skill Level: |
|
10 |
| Battery Tray Dimensions: |
|
155mm x 50mm x 29mm (adjustable height and length) |
| Required Batteries & Charger: |
|
Two Traxxas Power Cell LiPo batteries (LiPo, 3-Cell 5,000 mAh), 4 “AA” (transmitter), LiPo battery charger
|
|
| CASTLE CREATIONS MAMBA MONSTER EXTREME ESC SPECS |
| Input voltage (cells): |
|
18 NiMH 6s LiPo (max: 25.2 volts) |
| Case Size: |
|
2.2″ x 1.9″ x 1.4″ |
| Weight: |
|
4.27 ounces (121 grams) |
| On-Resistance (@Trans)–FWD/REV: |
|
0.0003 ohms per phase |
| Reverse Delay: |
|
Yes, with lockout |
| Low Voltage Detection (LVD): |
|
Yes, programmable |
|
